High-performance Non-Shrink Cement-based

Description Specifications Scope of Application FAQ Download

Description

The cementitious grout is primarily composed of high-strength aggregates, cement or specialized cement, supplemented with additives such as high-flow, micro-expansion, anti-segregation, etc. It is a homogeneous inorganic powder material mixed uniformly through mixing equipment. At the construction site, a certain amount of water is added, mixed evenly, and then injected into the reinforcement area to form a high-strength connection structure.

Specifications

PRODUCT INFOMATION

The finished product technical specifications comply with the requirements outlined in ASTM C348, ASTM C349, ASTM C940.

The typical data are shown in the table below:

No.	Item	Performance Index
1	Initial fluidity（20°C）/mm	≥290
2	30 minutes fluidity（20°C）/mm	≥260
3	Reaction temperature/°C	Normal temperature
4	Expansion ratio	0.1%-2%
5	Water-cement ratio	0.12-0.14
6	Bleeding rate/%	0
7	28-day dry shrinkage/%	≤0.045
8	Effect on steel reinforcement	No corrosion
9	40 Compressive strength/MPa	1d	3d	28d
9	40 Compressive strength/MPa	≥15	≥30	≥45
10	60 Compressive strength/MPa	1d	3d	28d
10	60 Compressive strength/MPa	≥20	≥40	≥60
11	80 Compressive strength/MPa	1d	3d	28d
11	80 Compressive strength/MPa	≥35	≥60	≥80

APPLICATION PROCEDURE

· Clean the surface of the foundation, ensuring no debris such as gravel or dust. Before grouting, the foundation surface should be kept moist, without standing water.

· On-site, determine the water-cement ratio based on the recommended ratio. Water temperature between 5-40°C is suitable, and mechanical or manual mixing can be used. Mechanical mixing should be done for 1-2 minutes. For manual mixing, first add 2/3 of the water and mix for 3 minutes, then add the remaining water and continue mixing until uniform.

· The grout should be poured from one side, not from all sides simultaneously. Grouting should be continuous without interruption, and efforts should be made to shorten the grouting time.

· After grouting is completed, any excess material that needs to be removed should be handled before the grout sets.

· After construction, immediately cover with plastic film and add grass curtains or blankets for moisture retention and curing.

TECNICAL INFOMATION

Product Technical Parameters	Packing Specification	25kg/bag
	Character	Grey mortar
	Mixing ratio	Powder: Water = 1:0.12-0.13 (by weight)
	Shelf life	12 months when stored unopened in a cool, dry place.
Construction Technical Parameters	Construction Consumption	2-3t/m³
	Construction Environment	Working temperature 5°C~35°C. Outdoor construction should be avoided in high temperature, frost, direct sunlight, or windy rainy weather. When the temperature is below 5°C, insulation measures should be done.
	Operable Time	30min

FEATURES AND BENEFITS

· Early strength, high strength:

Compressive strength（40）：1-3 days≥30 MPa, 28 days ≥45 MPa.

Compressive strength（60）：1-3 days≥40 MPa, 28 days ≥60 MPa.

Compressive strength（80）：1-3 days≥60 MPa, 28 days ≥80 MPa.

· High fluidity: Can fill all gaps in equipment foundations without vibration, meeting connection structure requirements.

· High stability: No shrinkage cracks or other defects after formation.

· Micro-expansion: Ensures tight contact between equipment and foundation after grouting.

· Strong durability: Belongs to inorganic bonding material, with a service life longer than that of basic concrete. Withstands hundreds of fatigue test and shows no significant changes in strength after 50 freeze-thaw cycles. Strength significantly increases after soaking in engine oil for 30 days.

Scope of Application

· Secondary grouting for equipment foundations.

· Reinforcement and repair of concrete structures.

· Anchoring of foundation bolts and column base plates.

· Anchoring of reverse construction joints in projects such as subways, tunnels, and underground structures.

· Secondary grouting for fixing connections between steel structures (such as steel rails, frames, and columns) and foundations.

FAQ

Q1: What are the main product series of VASA?

VASA's main product lines include tile and stone pasting series, waterproof mortar series, cement-based grouting material series, wall leveling and skimcoat series, inorganic flooring series, soil solidification products, etc.
Q2: Where is VASA's main production base?

VASA's main production bases are distributed throughout China, and there is also a factory in Johor Bahru, Malaysia.
Q3: What is VASA's production capacity?

The production capacity of VASA dry powder mortar products is approximately 7 million tons.
Q4: The production capacity of VASA dry powder mortar products is approximately 7 million tons.

The reference delivery time for VASA products is seven days within China, sea freight to South East Asia: 7-10 days; Europe/Americas: ~25–35 days; Latin America: ~20-45 days
Q5: Has VASA's product been certified for environmental protection? What are the certifications?

VASA's products have undergone environmental certification, including German GEV-EMICODE certification and French A+ certification.
Q6: What is the main packaging form of VASA products?

VASA's products are mainly packaged in valve pockets and transported on wooden pallets.
Q7: What are the auxiliary installation and construction supports?

We can provide construction videos of our main products to guide their construction.
