PRODUCT INFOMATION
The product complies with the standard requirements of C2TES1 in JC/T547-2017
classification. The main indicators are as follows:
|
No. |
Test Item |
Technical Specification |
|
1 |
Tensile Adhesion Strength / MPa |
≥1.0 |
|
2 |
Tensile Adhesion Strength after Immersion / MPa |
≥1.0 |
|
3 |
Tensile Adhesion Strength after Heat Aging / MPa |
≥1.0 |
|
4 |
Tensile Adhesion Strength after Freeze-Thaw Cycle / MPa |
≥1.0 |
|
5 |
Tensile Adhesion Strength after Airing for ≥30min / MPa |
≥0.5 |
|
6 |
Slip / mm |
≤0 .5 |
|
7 |
Lateral deformation/mm |
≥2.5,<5 |
TECNICAL INFOMATION
|
Product Technical Parameters |
Packing Specification |
25kg/bag |
|
Character |
Gray powder |
|
|
Executive Standard |
JC/T 547-2017 C2TES1 |
|
|
Shelf life |
12 months when stored unopened in a cool, dry place. |
|
|
Construction Technical Parameter |
Reference Dosage |
1.5kg/㎡/mm Actual consumption depends on the flatness of the base and the construction method |
FEATURES AND BENEFITS
· Ultra-flexible performance
· Crack-resistant and earthquake-resistant
· Environmentally friendly
|
Interior Applications |
Exterior Applications |
||
|
Suitable Substrate |
Suitable Tile Size |
Suitable Substrate |
Suitable Tile Size |
|
Stable substrates such as cement mortar and concrete |
≤1600×3200mm |
Stable substrates such as cement mortar and concrete |
≤600×1200mm |
|
Highly deformable substrates |
≤ 900×1800mm |
Highly deformable substrates |
≤300×300mm |
When tiling ceramic large slabs (thickness ≤ 12mm) with a surface area>1.62㎡ and a long edge>1500mm, especially in specific scenarios such as elevator shafts with significant deformation or extremely large slabs, mechanical fixing brackets need to be used in conjunction with the installation process.
