Packaging and specifications
| Project | Description | |
|
Product model |
PBXZ Semi-matt |
PQXZ Full-matt |
|
Film roll packaging |
The roll film is firmly bonded with tape at both ends and in the middle at the unwinding place, and a layer of bubble film is wrapped outside the roll, and the two ends are wrapped with endsealing bubble film. | |
|
Width a (mm) |
330-2200
|
|
|
Thickness a (um) |
22-24
|
|
|
Length a (m) |
6000-12000
|
|
|
Other |
Subject to customer requirements
|
|
Performance index
| Project | Index | Typical value | |
|
PXGS12 |
|||
|
Thickness (um) |
/ |
12.1 | |
|
Standard deviation of thickness |
±3% |
0.23 |
|
| Tensile strength(MPa) | MD | MPa |
≥ 100 |
| TD |
≥ 160 |
||
| Elongation at break(%) | MD |
% |
≤ 200 |
| TD |
≤ 70 |
||
| Wetting tension |
Matting side |
mN/m |
≤ 33(No corona) |
|
Glossy side |
≤ 33(No corona) |
||
|
Haze(%) |
% |
≥ 75 |
|
| Gloss(%) |
% |
≤ 10 |
|
Features & Benefits
· Has a soft, smooth and anti-blocking surface.
· The surface of the matting layer is highly delicate.
· Double-sided no corona treatment, good product transfer effect.
· Low density, low production cost and environmentally-friendly.
Soft smooth and anti blocking surface
Highly delicate matting layer surface
Double-sided no corona treatment,good product transfer effect
Low density low production cost and environmentally-friendly
