Packaging and specifications
| Project | Description |
|
Product model |
PFSS10/12/15 |
|
Packaging |
The film roll is curled cylindrical, protected by a bubble pad, and wrapped with a paper cover on both ends of the foam pad. |
|
Width a (mm) |
330-2200 |
|
Thickness a (um) |
10.0-15.0 |
|
Length a (m) |
6000-12000 |
|
Other |
Subject to customer requirements |
Performance index
| Project | Index | Typical value | ||
|
PFSS10 |
PFSS12 | |||
|
Thickness (um) |
/ |
9.5 |
11.6 |
|
|
Standard deviation of thickness |
±3% |
0.55 |
0.48 |
|
| Tensile strength(MPa) | MD | ≥120 |
170.3 |
169.6 |
| TD | ≥200 |
308.2 |
320.4 | |
| Elongation at break(%) | MD | ≤180 |
137.5 |
109.6 |
| TD | ≤65 |
49.3 |
36.3 | |
|
Heat shrinkage(%) |
MD | ≤4.5 |
4.3 |
3.5 |
| TD | ≤3.0 |
0.7 |
0.8 | |
|
Coefficient of friction (DCOF/ SCOF) |
T/T |
≤ 0.6 |
0.38/0.39 |
0.35/0.43 |
|
U/U |
≤ 0.6 |
0.32/0.37 |
0.29/0.41 | |
| Wetting tension / dyne / cm |
≥ 38 |
38 | 38 | |
|
Haze(%) |
≤ 2.0 |
1.77 |
1.63 | |
| Gloss(%) |
≥ 85 |
109.8 |
118.4 | |
Features & Benefits
· Good thickness uniformity and high surface flatness.
· Good transparency and high surface gloss.
· The corona treatment has high strength and high composite fastness to hot melt adhesive.
· The thickness is thin, and the unit weight is more than square meters.
Good thickness uniformity and high surface flatness
Good transparency and high surface gloss
High strength and high composite fastness
Thin thickness, high unit weight
