YuGuard PP-R Plumbing System

Description Specifications Scope of Application FAQ Download

Description

YuGuard PP-R (Polypropylene Random Copolymer) Plumbing System is a reliable and durable piping solution widely used in modern water supply and distribution. Manufactured from high-quality polypropylene materials, PP-R pipes and fittings are designed to withstand high temperatures and pressures, making them ideal for both hot and cold water applications. Their homogenous welding technique ensures leak-proof joints and a long service life. Compared with traditional piping materials, PP-R systems provide superior resistance to corrosion, scaling, and chemical impact. The smooth internal surface prevents deposits, ensuring clean and hygienic water. Lightweight and easy to install, PP-R pipes offer long-term cost efficiency for a wide range of projects.

Specifications

20-160mm

Features & Benefits

Durability – high resistance to pressure and temperature.

Corrosion-free – unaffected by rust, scaling, or chemical erosion.

Hygienic – non-toxic, safe for drinking water supply.

Leak-proof connections – achieved through heat fusion welding.

Energy-efficient – smooth inner walls reduce pressure loss.

Lightweight & easy installation – reduces labor and time costs.

Long service life – exceeding 50 years under normal conditions.

Scope of Application

Residential hot and cold water systems

Central heating and underfloor heating systems

Hospitals, hotels, and commercial buildings

Industrial fluid transport and compressed air systems

Municipal water supply networks

FAQ

Q1: What are the recommended fusion welding temperatures for PE and PP-R pipes?

The fusion welding temperatures vary depending on the material and are also affected by ambient temperature. For PE pipes, the recommended welding temperature is 210 ± 10°C, while for PP-R pipes it is 260 ± 10°C.
Q2: What are the maximum service temperatures and pressures for PE and PP-R pipes in water supply systems?

"PE pipes have a maximum service temperature of 40°C and a pressure rating of 1.6 MPa. PP-R pipes have a maximum service temperature of 70°C and a pressure rating of 1.0 MPa"
Q3: What are the available pressure ratings for PE pipes, and which are the most commonly used?

"PE pipes are available in eight pressure ratings, ranging from PN0.4 to PN2.0. The most commonly used ratings are: PN0.6, PN0.8, PN1.0, PN1.25, and PN1.6."
Q4: What are the standard pipe lengths for PE pipes, and how can the length be customized?

"PE pipes are supplied in both coils and straight lengths. Coiled pipes are typically supplied in 100-meter rolls. Straight pipes are generally 6 meters per length. Customized lengths are also available upon request, such as 9 meters or 12 meters per coil, depending on customer requirements."
Q5: What types of PE fittings are available, and how should they be selected?

"There are three main types of PE fittings: Socket fusion fittings (recommended for sizes DN20 to DN110) Butt fusion fittings (commonly used for sizes above DN110) Electrofusion fittings, which are commonly used in standard water supply systems and are typically applied in maintenance and repair scenarios."
