PET Spunbonded Waterproofing Bitumen Membrane Carriers

Home

Carriers

PET Spunbonded Waterproofing Bitumen Membrane Carriers

Description Specifications Scope of Application FAQ Download

Description

Tiandingfeng (TDF) polyester filament carrier adopts one-step polyester spun - bonded needle - punched production process with its own intellectual property rights. It is made of high - quality polyester chips and melt - spun to form continuous filaments then lapping, needle - punched consolidation, dipping, thermal setting, drying, etc., and many properties far exceed traditional carrier products.

Specifications

Typical Properties

Unit

Test Method

Tolerance

Standard Value

TDF Product Type

0120-AB

0130-AB

0140-AB

0150-AB

0160-AB

0170-AB

0180-AB

0190-AB

0200-AB

0220-AB

0230-AB

0250-AB

Mass per unit area

g/m²

DIN EN 29073

-5% *

120

130

140

150

160

170

180

190

200

220

230

250

Thickness

±15%

0.8

0.85

0.9

0.95

1.05

1.1

1.15

1.2

1.3

1.35

1.4

Max Tensile strength (MD/CD)

N/5cm

DIN EN 29073

-10% *

400/250

420/300

450/350

500/400

550/420

580/450

600/480

620/520

650/560

750/640

780/680

900/780

Elongation at max tensile strength (MD/CD)

DIN EN 29073

-15% *

25/28

26/30

28/30

30/32

30/35

32/35

35/40

Free load Shrinkage (MD/CD)

≤

1.5/1.0

Trapezoid Tear Strength (MD/CD)

TDF Internal control standard

-15% *

200/180

210/190

220/200

250/220

270/240

280/260

300/280

350/320

400/350

450/400

480/430

500/450

Scope of Application

TDF polyester roofing carrier is made by the process of "one step" polyester spunbond needle punch technics that owning independent intellectual property right. With stable quality, excellent performance, it is the best choice for production of SBS, APP waterproof membrane material.

FAQ

Q1: Are you a manufacturer?

A1: Tiandingfeng is a large business group dedicated to the development and production of all kinds of high-tech nonwovens. We have six production bases in Dezhou, Shandong Province, Chuzhou, Anhui Province, Changde, Hunan Province, Dammam, Saudi Arabia and Quebec, Canada, which can achieve an annual output of 280,000 tons.
Q2: What’s your products range?

A2: We are mainly focusing on the below products: 1)PET Spunbonded Waterproofing Bitumen Membrane Carriers; 2)Glass filament reinforced Polyester spunbond mat; 3)PET Nonwoven Geotextiles; 4)High Tenacity Coarse Denier Polypropylene Spunbond Needle Punched Geotextiles and Composite Geosynthetics.
Q3: What kind of qualification certificates do you have?

A3: We are ISO 9001, ISO 14001, ISO 45001 certified, and our products are CE certified for EU market access.
Q4: Can you provide the third-party test reports?

A4: Yes, we can supply SGS, BV, or TÜV third-party test reports for compliance verification upon request.
Q5: Can you offer private-label or OEM packaging?

A5: Yes, we can provide OEM services including logo printing, custom roll dimensions, barcode , and palletized export packaging.
