A new generation of green environmental protection special release film

Description Specifications Scope of Application FAQ Download

Description

It is a new generation of green environmental protection special release film prepared by solvent-free UV curing technology based on high-performance multi-material multi-layer co-extruded polypropylene (PP) film.

Specifications

Product Details

**Release Film PV2580BG**
Construction	PP/NylonFilm		Color	Black/Grey
Typical physical properties
Property	Unit	Target	LSL	USL	Method
Thickness	um	25	23	27	ASTMD374
Basic weight	gsm	23	21	25	ASTMD3776
Tensile strength(MD)	N/50mm	/	70	/	ASTMD882
Elongation at break(MD)	%	/	300	/	ASTMD882
Tensile strength(CD)	N/50mm	/	30	/	ASTMD882
Elongation at break(CD)	%	/	300	/	ASTMD882
Release force	g/inch	/	/	20	FTM10
Subsequent adhesion	%	/	80	/	FTM11

Release Film PV2560BG

Construction	PP/NylonFilm		Color	Black/Grey
Typical physical properties
Property	Unit	Target	LSL	USL	Method
Thickness	um	25	22	28	ASTMD374
Basic weight	gsm	24	21	27	ASTMD3776
Tensile strength(MD)	N/50mm	/	70	/	ASTMD882
Elongation at break(MD)	%	/	300	/	ASTMD882
Tensile strength(CD)	N/50mm	/	30	/	ASTMD882
Elongation at break(CD)	%	/	300	/	ASTMD882
Release force	g/inch	/	/	20	FTM10
Subsequent adhesion	%	/	80	/	FTM11

Release Film PV3080BG

Construction	PP/NylonFilm		Color	Black/Grey
Typical physical properties
Property	Unit	Target	LSL	USL	Method
Thickness	um	25	22	28	ASTMD374
Basic weight	gsm	24	21	27	ASTMD3776
Tensile strength(MD)	N/50mm	/	70	/	ASTMD882
Elongation at break(MD)	%	/	300	/	ASTMD882
Tensile strength(CD)	N/50mm	/	30	/	ASTMD882
Elongation at break(CD)	%	/	300	/	ASTMD882
Release force	g/inch	/	/	20	FTM10
Subsequent adhesion	%	/	80	/	FTM11

Release Film PV3080W

Construction	PP/NylonFilm		Color	Black/Grey
Typical physical properties
Property	Unit	Target	LSL	USL	Method
Thickness	um	30	27	33	ASTMD374
Basic weight	gsm	29	26	32	ASTMD3776
Tensile strength(MD)	N/50mm	/	90	/	ASTMD882
Elongation at break(MD)	%	/	300	/	ASTMD882
Tensile strength(CD)	N/50mm	/	50	/	ASTMD882
Elongation at break(CD)	%	/	400	/	ASTMD882
Release force	g/inch	/	/	20	FTM10
Subsequent adhesion	%	/	80	/	FTM11

Release Film PV3060BG

Construction	PP/NylonFilm		Color	Black/Grey
Typical physical properties
Property	Unit	Target	LSL	USL	Method
Thickness	um	30	27	33	ASTMD374
Basic weight	gsm	29	26	32	ASTMD3776
Tensile strength(MD)	N/50mm	/	80	/	ASTMD882
Elongation at break(MD)	%	/	300	/	ASTMD882
Tensile strength(CD)	N/50mm	/	40	/	ASTMD882
Elongation at break(CD)	%	/	300	/	ASTMD882
Release force	g/inch	/	/	20	FTM10
Subsequent adhesion	%	/	80	/	FTM11

Release Film PV3580BG

Construction	PP/NylonFilm		Color	Black/Grey
Typical physical properties
Property	Unit	Target	LSL	USL	Method
Thickness	um	35	32	38	ASTMD374
Basic weight	gsm	32	29	32	ASTMD3776
Tensile strength(MD)	N/50mm	/	90	/	ASTMD882
Elongation at break(MD)	%	/	30	/	ASTMD882
Tensile strength(CD)	N/50mm	/	50	/	ASTMD882
Elongation at break(CD)	%	/	400	/	ASTMD882
Release force	g/inch	/	/	20	FTM10
Subsequent adhesion	%	/	80	/	FTM11

Release Film PV3560BG

Construction	PP/NylonFilm		Color	Black/Grey
Typical physical properties
Property	Unit	Target	LSL	USL	Method
Thickness	um	35	32	38	ASTMD374
Basic weight	gsm	32	29	35	ASTMD3776
Tensile strength(MD)	N/50mm	/	90	/	ASTMD882
Elongation at break(MD)	%	/	300	/	ASTMD882
Tensile strength(CD)	N/50mm	/	40	/	ASTMD882
Elongation at break(CD)	%	/	300	/	ASTMD882
Release force	g/inch	/	/	20	FTM10
Subsequent adhesion	%	/	80	/	FTM11

All technical data given here are approximated and only intend to provide you with general guidance for using this film. They are based upon tests believed to be reliable but do not constitute a guarantee or warranty. The material is storable up to 6 months max under unobjectionable storage conditions.

Features & Benefits

· Uniform thickness, thickness tolerance (2sigma) ±2.5%.

· Lightweight and high strength, good tear resistance.

· Excellent bitumen adhesion, oil resistance and yellowing resistance。

· Stable release, low silicon transfer, easy to remove during construction.

· No VOCS emission,low carbon and environmental protection.

Scope of Application

It is suitable for isolation and protection of adhesive materials such as waterproof membranes, tapes, and self-adhesive labels.

FAQ

Q1: How many BOPP production lines does Golden Wrapping have?

Currently we have two BOPP production lines.
Q2: What kind of products GOLDEN WRAPPING can provide?

We are able to provide BOPP thick glossy film, as well as different specifications of glossy film and matte film, including BOPP bag film, BOPP printing film,BOPP Paper Lamination Film,BOPP Matt Film, heat sealing film, and we can also provide cpp products, as well as PE film products.
Q3: Where is Golden Wrapping's factory located?

Our company is located in Jiangsu Province, China.
Q4: What is the general lead time?

Production: Scheduling according to specifications 7-10 days; Shipping to Southeast Asia: 7-10 days; Europe/America: ~25-35 days; Europe/America: ~25-35 days: ~25-35 days;
Q5: What is your capacity？

Our annual capacity is around 70,000 tons bopp film and 14000 tons cpp film, and 21000 tons pe film
Q6: What is your quality ?

We have two test to keep quality, one is in production, and after produce, we will have a test again
